Roller width: 170cm （other drum widths are available） Printing width: 155cm Drum diameter: 42cm Heating method: Oil heating Table length: 2m, 3m, etc.
Features
This calendar roller heat transfer machine is very suitable for printing fabrics, clothing textiles, work clothes, etc. Our heat press machine has Italian quality and is very stable.
The price and service must be the best. We have a complete pre-sales and after-sales team to solve the problem and all your questions.
This machine has a comprehensive safety system, such as the emergency stop triggered by hand clapping, the machine stop button, and the automatic blanket return function, which can prevent the blanket from being burned in case of an accident.
It has an innovative blanket automated deviation correction mechanism, which may prevent inadvertent damage brought on by the blanket's deviation and lower our use costs.
It is possible to have an intelligent touch screen system installed, which is easier to use and saves time and work.
It has a cutting-edge and secure workstation system that includes rewinding cloth, rewinding waste paper, counting quantity, etc.
It is equipped with the intelligent security system of the whole machine, and it will automatically warn and remind if there is a failure during use.
We have a complete set of user manuals plus our training, which can solve any of your problems.
Technical parameters
No | Item | Data |
1 | Drum type | Durable chrome-plated double-layer |
2 | Drum diameter | 420mm |
3 | Drum width | 1700mm (other drum widths are available) |
4 | Temperature range | 0-260℃ |
5 | Control | Button control |
6 | Main motor power | 0.75KW |
7 | Other motors power | 0.15KW and 0.18KW, etc. |
8 | Preheating power for 380V 3 phase | 25KW |
9 | Amperage for 380V 3 phase | 38A |
10 | Preheating power for 220V 3 phase | 22KW |
11 | Amperage for 220V 3 phase | 58A |
12 | Automatic pneumatic pressure | Yes |
13 | Automatic blanket alignment | Yes |
14 | Adjustable blanket length | Yes |
15 | Automatic blanket moving | Yes |
16 | Number of air shaft | 2 |
17 | Working way | Roll to roll, roll to pieces, pieces to pieces |
18 | Packing dimension | 270x150x158cm |
Calandra dimension
Working flow
Heat press calendar package
FAQ:
Q1: Is it oil heated?
A1: Yes, it is oil heated.
A2: If the printing width is 1,55 m, you can choose the 1,7 m drum width.
A3: Sublimation speed is 80 to 100 meters per hour.
A4: We use the chrome-plated drum. It is more durable, anti-stretching, etc.
Quality control for roll heat press
How to choose a suitable calander sublimation
How to maintain the roll heat press
