Drum type: chrome-plated Heating type: Oil heating Suitable for: Roll to roll and roll to pieces sublimation fabric printing Temperature range: 0-260℃ Sublimation speed: Adjustable
USD6000-USD6900
Features
The circuit breaker will automatically trip if the machine has electricity leakage problem. It is for the safety of the operator.
The “forcing” ( pneumatic pressure) can be turned on and turned off according to the substrates. If koozies , curtain fabric, etc. are sublimated, it should be off. If the nylon fabric is sublimated, it should be on.
The torque limiter is for adjusting the tension of sublimation paper after it get through to the air shaft. When you pull it to the table, it should be adjusted to get the best result.
2 air shafts help you quickly remove used sublimation paper roll and used protective paper roll. The rolling heat press has a nozzle for air that can be used to expand the air expansion shaft. Simply press the button on the air expansion shaft to deflate if necessary.
Technical parameters
Model | HB21-3 |
Drum type | Durable chrome-plated drum |
Drum diameter | 215mm |
Drum width | 180cm ( other drum widths are available) |
Temperature range | 0-260℃ |
Touchscreen control | Yes |
Language | English and Espanol |
Total power | 11KW |
Heat transfer power | 7.7KW |
Automatic shutdown | Yes |
Automatic blanket alignment | Yes |
Adjustable blanket length | Yes |
Safety design | Yes |
Heating type | Thermal oil heating |
Voltage | 220V 1 phase/220V 3 phase/380V 3 phase |
Number of air shaft | 2 |
Working way | Roll to roll, roll to pieces, pieces to pieces |
Packing dimension | 265x101x152cm |
Working flow
Sublimation calender dimension
Quality control for roll heat press
How to choose a suitable calander sublimation
How to maintain the roll heat press
