Roller width: 1200mm (available in other widths) Roller diameter: 210mm Heating method: Oil heating Roller type: Chrome-plated Voltage: 220V 1 phase, 220V 3 phase and 380V 3 phase
Features
This 210mm roller diameter, 1200mm roller width calender heat press doesn't require you have the 3-phase power. Using it instead of a large flat heat press can help you save electricity costs while increasing production.
This calandra has a pressure roll that is connected to an air cylinder. When the "forcing" button is pressed, the roll will be moved by the air cylinders on the left and right sides to make greater contact with the blanket.
After some time passes, the blanket's circumference will get longer. If the blanket is too loose, the roll can be changed to the following position to make it tighter.
It is a regular version calendar. So it has an automatic blanket alignment system. The automatic deviation correction system can avoid the waste of materials caused by the transfer defects caused by the deviation of the felt, and can avoid the cost of replacing the felt caused by the deviation of the felt and the friction to the machine wallboard to damage the blanket
It has a conveyor belt that can transport the printed pieces to the end of the table.
Sublimation paper and protective paper tension can be adjusted by their own speed reducers.
The air shaft is for used sublimation paper taking up.
At the end of working day, automatic shutdown button can be hit, when it cools down to 90℃， it will automatically shut off.
Technical parameters
Item | Data |
Control panel | Digital button control |
Drum diameter | 215mm |
Drum width | 1200mm (other drum widths are available) |
Temperature range | 0-260℃ |
Pressure range | 0-8kg |
Total Power | 8KW |
Main motor power | 0.4KW |
Heat transfer power | 5.6KW |
Automatic shutdown | Yes |
Automatic blanket alignment | Yes |
Adjustable blanket length | Yes |
Safety design | Yes |
Heating type | Thermal oil heating |
Voltage | 220V 1 phase/220V 3 phase/380V 3 phase |
Number of air shaft | 1 |
Working way | Roll to roll, roll to pieces, pieces to pieces |
Packing dimension | 205x101x156cm |
Working flow
Sublimation press calender dimension
FAQ
Q1: Is it oil heated?
A1: Yes, it is oil heated.
Q2: Which drum width is suitable for me?
A2: If the printing width is 1050 mm, you can choose the 1200 mm drum width.
Q3: How many meters per hour it can transfer?
A3: Sublimation speed is 35 to 50 meters per hour.
Q4: Why do I need the automatic pneumatic pressure function?
A4: It is perfect for thin fabric especially those are less than 100 grams. And with the pneumatic pressure, you can sublimate with higher speed.
Q5: What is air shaft?
A5: Air shaft means it will be inflatable after you charge air for it. Use the air expansion to secure down paper tube instead of screws.
Quality control for roll heat press
How to choose a suitable calander sublimation
How to maintain the roll heat press
